The equipment can be equipped with spheroidization and nanoscale powder production process modules, allowing users to conveniently produce metal and non-metal powders according to their needs.
The microwave plasma flame temperature ranges from 3,000 to 6,000 K, achieving basic full coverage of metals and ceramic materials.
It features high energy density and uniform distribution, resulting in rapid reaction rates.
The plasma can be precisely controlled by adjusting the microwave power and gas flow pressure.
It is clean, green, energy-efficient, and environmentally friendly.
Equioment type | SLWB-15 | SLWB-25 | ||
| Total power | 40KW, 380V±5%, Three-phase five-wire system | 50KW, 380V±5%, Three-phase five-wire system | ||
| Microwave plasma power | 15KW | 25KW | ||
| Input raw materials | Support non-spherical metal/non-metal powder raw materials with a particle size of 1~200μm | |||
| Powder particle size |
| |||
| Ultimate vacuum | ≤10 Pa，Vacuum pumping method by mechanical pump and water ring pump | ≤15 Pa，Vacuum pumping method by mechanical pump and water ring pump | ||
| Cooling method | Water cooling, and supporting water cooler circulation cooling | |||
| Atmosphere | N2（Purity ≥ 99.999%, dew point ≤-70°C） | |||
| Process package |
|
| ||
| Control system | PLC and industrial computer to monitor temperature/pressure/flow rate in real time | |||
| Equioment size | 3000×900×1970 mm3 (L×W×H) | 4700×3300×2700 mm3 (L×W×H) | ||
| Equioment weight | ~1.5t | ~2.5t | ||
Spheroidized powders: titanium alloys, iron-based alloys, refractory metals and their alloys, high-temperature alloys, high-temperature ceramics, etc.
Nanopowders: Si, Cu, Ni, carbides, nitrides, oxides, etc.
